Smart machining program with DXF import
smartEDIT
Software tool for easy creation of NC machining programs
Simply bring dispensing curves onto the machine
With smartEDIT, you no longer need programming knowledge for G-code to create simple dispensing curves on bdtronic dispensing systems. The software tool with simple user interface creates the NC machining program via input masks with graphical support. Via software functions a conversion of DXF contours or also a manual contour input are possible.
Software features
Import of DXF data or manual input of the contour with graphical support
Setting and editing start points within the part program
Integration of dosing quantities into the machining program
Re-editing contour areas
Editing the start and end of a contour
Options
Calling and copying subprograms
Integration of wiping routines
Re-edit machining direction and sequence
Selection of several approach strategies for individual contours within the component
Freely configurable palletizing functions
Benefits
Editing program can be saved for later adaptation
Intuitive operator guidance
Fast changes / editing of the machining program with automatic recalculation of the NC code without NC knowledge
Graphical view of the dispensing contour
Requirements
License activation via licensing file (license is PC-bound)
DXF data type: AutoCAD 2000-2018
DXF saved as ascii file (text file, not binary)
The following contours are supported: Line I Polyline I Circle I Arc
Request smartEDIT
You want to try smartEDIT and get an offer? Fill out the form and get your offer and your personal license.
